Triple Crown 8.5x24 Deck over equipment

Basic Specifications

1. Overall Length: 24 ft
2. Deck Width: 102 in (8 ft 6 in)
3. Deck Type: Deck-over (full-width deck above wheels)
4. Flat Deck: ~20 ft
5. Dovetail: ~4 ft rear dovetail
6. Trailer Type: Bumper-pull equipment trailer
7. Coupler: Adjustable 2-5/16″ ball coupler

Weight Ratings

1. GVWR: typically 14,000 – 16,000 lbs depending on axle option
2. Trailer Empty Weight: about 2,900 – 4,600 lbs
3. Payload Capacity: about 10,500 – 11,400 lbs

Axles / Suspension

1. Axles: Tandem axles
2. Common setups:
3. (2) 7,000 lb brake axles (14K GVWR version)
4. (2) 8,000 lb Dexter brake axles (16K version)
5.

6. Axle Type: Electric brakes with EZ-lube or oil bath hubs

Frame & Deck Construction

1. Frame: Heavy steel channel frame
2. Tongue: A-frame wrap tongue
3. Decking: 2×8 treated lumber wood deck
4. Rub Rail + Stake Pockets: for tie-downs
5. DOT reflective tape

Loading Features

1. Rear Ramps:
2. 5–6 ft spring-assist flip-up ramps
3.

4. Dovetail: 4 ft wood dovetail for easier loading angle
5. Spare Tire Mount

Electrical / Safety

1. Full LED lighting
2. 12V breakaway brake kit
3. Safety chains
